Product Features & Specifications
Key Features
- Certification
- BS EN 12101-3 certified
- Application
- Car parks, basements, deep-plan escape routes
- Design
- Ductless impulse / induction fan
- Speeds
- Dual-speed for daily CO + smoke purge
- Isolator
- IP65 lockable, fire-rated (supplied as standard)
- Airflow
- Unidirectional, high-velocity jet
Technical Specifications
- Standard
- BS EN 12101-3
- Mounting
- Soffit / ceiling, ductless
- Operation
- Fire-triggered via AOV control panel
- Thrust Range
- 54N (E50N) to 98N (E100N)
- Volume Flow
- 1.63 m³/s (E50N) to 2.65 m³/s (E100N)
